P800 Direct Operating Factory Preset Relief Valve
The inline P800 direct operating factory preset relief valve is designed for use in pneumatic applications that warrant protection from overpressurization. The P800 is used primarily between a pneumatic instrument and a supply regulator to limit the instrument supply pressure to 50 PSIG in the case of a supply regulator failure.
Features:
- Non-rising Adjustment Assembly
- Large 0.344 Relief Seat Diameter
- Rolling diaphragm for enhanced accuracy
- Tamper resistant spring case
Specifications
Port Size
1/4" NPT
Connection
NPT
Spring Range
2 PSIG - 50 PSIG
Application(s)
Instrument air supply
Temperature Range(s)
20˚ to 150˚ F (-29˚ to 66˚ C)
Find Your Part Number
Not sure? Call for help. Phone: 1-800-833-3127
