P350 Aluminum NACE Filter
The Type P350 NACE compliant filter is a high-reliability filter, complying with NACE MR1075 for sulfide stress cracking resistant metallic material for use with oil field equipment. A tight seal is guaranteed by the use of a thread element connection. The filter housing and element have been polished and degreased. No special lubricants are needed in the field for replacing the element. The element is threaded into the housing so there is no need for extra parts during installation or maintenance of the filter. There is no chance of losing top or bottom seals or rings required for installation.
Applications:
- Filtering Supply Gas
- Filtering Air Supply
Features:
- High-reliability filter
- Compliant with NACE MR1075
- Choice of drain or manual valve drain
- Threaded element design alleviates need for extra parts at installation
- Aluminum option available
Specifications
Model
P350
Body Sizes
1/4" NPT
Application(s)
Industrial
Pilot Operated
No
Connection
NPT
Product Description
Type P350 NACE Compliant Filter
Temperature Range(s)
248°F (120°C)
Max Inlet Body Pressure
Aluminum 2150 PSIG Stainless Steel 5000 PSIG
Body, Bonnet, Diaphragm Material
Body, Stainless Steel (NACE) Construction or Aluminum Filter 25 Micron Glass Microfiber (Standard) Stainless Filter End Caps
Find Your Part Number
Not sure? Call for help. Phone: 1-800-833-3127
